Product Details:
|
| Model: | SR405R 2020 | Engine Model: | Isuzu 6WG1 |
|---|---|---|---|
| Engine Power: | 377KW | Dimension: | 10160mm*4300mm*27420mm |
| Operating Weight: | 122000kg | Emission Regulation: | Tier III |
| Max. Pile Depth: | 106/87m | Max. Pile Diameter: | 2500/2200 Mm |
| High Light: | Sany Used Rotary Drilling Rig,SR405R 2020 Used Rotary Drilling Rig,377KW Used Rotary Drilling Rig |
||
Sany Used Rotary Drilling Rig SR405R 2020
| Product Description | |||
| Sany Used Rotary Drilling Rig SR405R 2020 | unit | Parameter | |
| Pile | Max. Pile diameter | mm | 2500/2200 |
| Max. Pile depth | m | 106/87 | |
| Rotary Drive | Rated output torque | KN-m | 405 |
| Rated Speed | rpm | 5~25 | |
| Crowd System | Crowd Force | KN | 350 |
| Line Pull | KN | 400 | |
| Stroke | mm | 13000 | |
| Main Winch | Lifting Capacity | KN | 400 |
| Ripe Diameter | mm | 36 | |
| Max. line speed | m/min | 75 | |
| Main Chassis | base engine | ISUZU 6WG1 | |
| Engine power | KW/rpm | 377/1800 | |
| Emission Regulation | Tier III | ||
| Overall | Overall height | mm | 27700 |
| Operating weight | t | 131 | |
| Transport Width | mm | 3500 | |
| Transport Height | mm | 3660 | |
