Product Details:
|
| Controls: | Joystick, Foot Pedal | Drive Type: | Electric |
|---|---|---|---|
| Foldable: | Yes | Working Height: | 6.5m |
| Number Of Wheels: | 4 | Power Source: | Battery |
| Product Name: | Scissor Boom Lift | Safety Features: | Sensors, Alarms, Interlocks |
| Warranty: | 1 Year | Weight: | 890kg |
| Highlight: | CE Scissor Boom Lift,6.5m Working Height Man Lift,Skyboom Man Lift |
||
Skyboom Scissor Lift
| Model | SSL-08DC |
| Working height maximum(A) | 6.5m |
| Platform height maximum(B) | 4.5m |
| Overall length | 1.43m |
| Overall width | 0.78m |
| Height (rails up) | 2.05m |
| Height (rails down) | 1.68m |
| Platform size (L*W) | 1.3m×0.7m |
| Platform extension size | 0.6m |
| Wheel base | 1.08m |
| Ground clearance (stowed) | 0.07m |
| Ground clearance (raised) | 0.02m |
| Load capacity | 240kg |
| Extension platform load capacity | 120kg |
| Travel speed (stowed) | 3.5km/h |
| Travel speed (raised) | 0.8km/h |
| Gradeability ( stowed) | 25% |
| Turning radius (inside) | 0.22m |
| Turning radius (outside) | 1.55m |
| Working slope maximum | 1.5°/3° |
| Tyres | ￠230×80mm |
| Drive & lifting motor | 24V/3.5KW |
| Battery | 12v*2/115Ah |
| Integrated charger | 24V/25A |
| Weight | 890kg |
