Product Details:
|
| Model: | CAMC CM6D18 340 31 | Capacity: | 10m3 |
|---|---|---|---|
| Engine Power: | 340 HP | Gear Box: | FAST Company, 9JSD150T-B |
| Dimmensions: | 9800*2500*3950 (mm) | Weight: | 14500 Kg |
| High Light: | Second Hand CAMC Mixer Truck,10M³ CAMC Mixer Truck Second Hand,Second Hand Transit Mixer 340HP |
||
| Model | CAMC Truck Mixer 10M³ Model 2019 | |
| Overall Parameters | Rudder Direction | Left |
| Curb Weight(kg) | 12800 | |
| GVW(kg) | 43650 | |
| Dimension (L×H×W)(mm) | 9800×2500×3950 | |
| Wheel Base(mm) | 3600+1350 | |
| Min. Ground Clearance(mm) | 255 | |
| Min. Turning Diameter(m) | ≤20 | |
| Fuel Consumption(L/100km) | ≤45 | |
| Braking Distance(V0=30km/h)(m) | ≤10(Full load); ≤9(Empty load) | |
|
Chassis |
Engine Model | CAMC CM6D18 340 31 |
| Displacement(L) | 9.84 | |
| Rated Power/Rev Speed(kW/rpm) | 250/1900 | |
| Max. Torque/Rev Speed(N.m/rpm) | 15700/1250 | |
| Emissions | Euro-2 | |
| Gear-box | FAST company, 9JSD150T-B | |
| Front Axle(t) | 9 | |
| Intermediate, Rear Axle(t) | 2×16 | |
| Tyre | 11.00R22.5 | |
|
Pneumatic dual- circuit braking system with drum |
||
| Fuel Tank Capacity(L) | 380 | |
|
Drum |
Capacity(m3) | 10 |
| Feeding Speed(m3/min) | ≥8 | |
| Discharge Speed(m3/min) | ≥5 | |
| Discharge Residual Rate | ≤0.5% | |
| Slump(mm) | 50 － 210 | |
| Water Tank Capacity(L) | 400 | |
| Water Pressure(MPa) | 0.35-0.38 | |
| Reducer | ZF P5300/Germany
|
|
| Hydraulic Pump | Rexroth A4VTG90 PUMP Germany | |
| Motor | Rexroth A2FM90 Germany |
|
