Product Details:
|
| Concrete Pump Brand: | Zoomlion | Model: | ZLJ5419THB 52X-6RZ |
|---|---|---|---|
| Engine Emission Standard: | Euro3/14 256L | Max Torque(N-m): | 2059 |
| GVW(Kg): | 40500 | Chassis: | Isuzu CYH51Y |
| Engine: | Isuzu 6WF1D | Vertical Reach: | 52m / 6 Section |
| Type Of The Cabin: | Isuzu CYH51Y | ||
| High Light: | Used Zoomlion Concrete Pump Truck,2014 Zoomlion Concrete Pump Truck,Zoomlion 52M |
||
| Product Discription | |||
| Item | Parameter | ||
| Concrete pump brand | Zoomlion | ||
| Model | ZLJ5419THB 52X-6RZ | ||
| Fedding height | 1400mm | ||
| Fuel type | Diesel | ||
| Engine emission standard | Euro3/14 256L | ||
| Max output power(Kw/rpm) | 287/1800 | ||
| Max torque(N-m) | 2059 | ||
| Type of the cabin | Isuzu CYH51Y | ||
| Rear axle: ratio/loading capacity | 25.8tons | ||
| Braking system | Full air,dual circuit | ||
| Wheelbase(mm) | 1850+4605+1310 | ||
| Tire | 295/80R22.5 | ||
| GVW(Kg) | 40500 | ||
| Chassis | Isuzu CYH51Y | ||
| Engine | Isuzu 6WF1D | ||
| Vertical reach | 52m / 6 section | ||
| Pipe size | 125mm | ||
| Boom&Pump system End Hose(L·D) | 3000*125mm | ||
| Output(Low/High-pressure) | 200/140㎡/h | ||
| Pressure(Low/High-pressure) | 8.3/12Mpa | ||
