Product Details:
|
| Model: | HBT8018 C5 2015 | Color: | Yellow And Red |
|---|---|---|---|
| Dimensions: | 7330*2125*2685mm | Weight: | 7300lkg |
| Engine Rated: | 180KW | Type: | S-Valve |
| High Light: | HBT8018C Used Concrete Trailer Pump,Used Concrete Trailer Pump 180kw |
||
Used Sany Yellow HBT8018C Concrete Trailer Pump Model 2015
Sany Proudct Discription:
| Model | Sany HBT8018 C5 2015 |
| Place of Production | China |
| Color | Yellow and Red |
| Type | S-Valve |
| Max.delivery pressure(theoretical) Low pressure/High pressure(Mpa) | 10 / 18 |
| Max.concrete output(theoretical) Low pressure/High pressure(m3/h) | 85 / 50 |
| ross weight (kg) | 7300 kg |
| Engine rated power(kw) | 180 |
| Rated Rotary Speed (rpm) | 2200 |
|
Delivery cylinder Bore (mm) *Strok(mm) |
Φ200 × 1800 |
| Hopper capacity (m3)* Feeding heigh(mm) | 0.7 × 1420 |
| Dimension (L*W*H) (mm) |
7330mm × 2125mm × 2685mm |
| Max. aggregate size: Φ150 mm delivery pipe (mm) | 50 |
| Max. aggregate size: Φ125 mm delivery pipe (mm) | 40 |
| Slump of concrete (mm) | 100 ～ 230 |
