Product Details:
|
| Model: | HBT60C Electric Concrete Trailer Pump Model 2016 | Color: | Yellow And Red |
|---|---|---|---|
| Dimensions: | 6590×2100×2200mm | Weight: | 5880kg |
| Motor Power: | 75KW | Type: | Gate Valve |
| High Light: | 75KW Used Electric Concrete Trailer Pump,Sany Used Electric Concrete Trailer Pump,HBT60C trailer concrete pump Used |
||
| Model | Sany HBT60C 2016 |
| Place of Production | China |
| Max.delivery pressure(theoretical) Low pressure/High pressure(Mpa) | 7 |
| Max.concrete output(theoretical) Low pressure/High pressure(m3/h) | 70 |
| Motor rated power (kw) | 75 |
| Rated Rotary Speed (rpm) | 1480 |
| Delivery cylinder Bore (mm) *Strok(mm) | Φ200×1400 |
| Hopper capacity (m3)* Feeding heigh(mm) | 0.6× 1415 |
| Dimension (L*W*H) (mm) | 6590×2100×2200 |
| Gross weight (kg) | 5880 |
| Max. aggregate size: Φ150 mm delivery pipe (mm) | 50 |
| Max. aggregate size: Φ125 mm delivery pipe (mm) | 40 |
| type | Gate Valve |
| Slump of concrete (mm) | 100 ~ 230 |
