Product Details:
|
| Model: | SCC550E | Color: | Yellow |
|---|---|---|---|
| Engine: | 200 KW/rpm | Fuel Tank: | 400L |
| Weight: | 28.5 T | Dimensions: | 7030 Mm × 3360 Mm × 3304 Mm |
| Max Boom Length: | 13m-52m | Capacity: | 55t |
| High Light: | Used Crawler Crane 50 Ton,SCC550E Used Crawler Crane,Used sany crawler crane 50 ton |
||
Used Sany 50 tons SCC550E Crawler Crane Model 2016
|
Product Discription
|
|
|
Max.Lifting Capacity
|
55 ton |
| Crane Type | Sany Crawler Crane SCC550E |
| Max Crane Boom Length | 13 m - 52 m |
| Max.Fixed Jib Combination | 43+15.25 m |
| Swing Speed | 0 - 2 rpm |
| Travel Speed | 0 - 1.2 km/hr |
| Boom Operating Condition - Boom Luffing Angle | 30° - 80° |
| Boom Operating Condition - Max. Rated Lifting Torque | 203.5 t•m |
| Fixed Jib Operating Condition - Angle between boom and jib | 10°, 30° |
| Operating Speed - Rope Speed of Main and Auxiliary Winches | 0 - 120 m/min (third layer) |
| Operating Speed - Rope Speed of Luffing Winches | 0 - 72 m/min (forth layer) |
| Engine - Output Power/Rate Speed | 132 / 200 kW/rpm |
| Engine - Fuel Tank | 400 L |
| Engine - Max. torque | 800 N·m 1400 rpm |
| Engine - Rated Power | 132 kW / 2200 rpm (considered the matching with the pump, rated power is limited to 132 kW / 2000 rpm) |
| Transportation Parameter - Max. Transportation Weight of Single Piece | 28.5 ton (including boom base and undercarriage but not including counterweight) |
| Transportation Parameter - Transportation Dimension(Length×Width×Height) | 7030 mm × 3360 mm × 3304 mm |
| Average Ground Pressure | 0.061 MPa |
