Product Details:
|
| Model: | QUY100 XCMG | Color: | Yellow |
|---|---|---|---|
| Engine Power: | 200 KW | Max Lifting Capacity: | 100 T |
| Weight: | 40 T | Dimensions: | 9.6m×3.3m×3.3m |
| Boom Length: | 18~72m | Travel Speed: | 1.1km/h |
| High Light: | Used 100 Ton Crawler Crane,XCMG Used 100 Ton Crawler Crane,QUY100 Used Crawler Crane XCMG |
||
Used XCMG 100 tons QUY100 Crawler Crane Model 2013
| Product Discription | |||
|
XCMG QUY100 Crawler Crane
|
Unit | Parameter | |
| Max. lifting capacity | Boom | t | 100 |
| Jib | t | 11 | |
| Boom single top | t | 10 | |
| Max. load moment | t.m | 5500 | |
| Boom length | m | 18~72m | |
| Boom elevating angle | ° | 30~80° | |
| Fixed jib length | m | 12~24 | |
| Max. single line elevating speed (at 5th layer with no load) | m/min | 45 | |
| Max. swing speed | r/min | 1.4 | |
| Travel speed | km/h | 1.1 | |
| Max. grade-ability | % | 30 | |
| Mean ground pressure | MPa | 0.0927 | |
| Engine output | kW | 200 | |
| Total mass (main hook block,18m boom) | t | 114 | |
| Max. mass of single unit in travel configuration (without counterweight, L/R crawler, lattice boom) | t | 40 | |
| Max. base machine dimension for transport (L×W×H) | m | 9.6m×3.3m×3.3m | |
