Product Details:
|
| Model: | ZCC5200S Model 2019, | Max Lifting Capacity: | 400 T |
|---|---|---|---|
| Max Lifting Moment: | 2360/520 T.m | Wind Turbine Boom: | 106+7m |
| Engine Brand: | Weicai | Engine Power: | 318/1900 Kw/rpm |
| Max Length Of Heavy Boom: | 84m | Operation Weight: | 48.6 T |
| Rated Power: | 360/1800 KW/r/min | Year: | 2019 |
| High Light: | Second Hand 400 Ton Crawler Crane,ZCC5200S Second Hand 400 Ton Crawler Crane,Second Hand Crawler Crane Zoomlion |
||
Used Zoomlion 400 tongs ZCC5200S Crawler Crane Model 2019
| Product Discription | ||||
| Item | Unit | Value | ||
| Max. lifting capacity on heavy duty boom(S)/Radius | Without D and B t × m | 450 × 6 | ||
| With D and B m | 500 × 12 | |||
| Length of heavy duth boom(S) | Without D and B m | 24-90 | ||
| With D and B m | 36-96 | |||
| Length of light duty boom(SL) | Without D and B m | 48-108 | ||
| With D and B m | 78-126 | |||
| Dead weight of crane with basis boom | m | 370 | ||
| Length of luffing jib(W) | m | 28-84 | ||
| Max.lifting capacity on luffing jib | Without D and B t × m | 190 × 13 | ||
| With D and B t × m | 235 × 16 | |||
| Boom angle when luffing jib is used | . | 65,75,85 | ||
| Max. length of heavy duty boom with | Without D and B m | 60+72 | ||
| With D and B m | 84+84 | |||
| SLHS boom | Main boom m | 84-108 | ||
| Wind plant jib m | 7 | |||
| Max.lifting capacity t×m | 126×16 | |||
| Single rope speed of winches | Hoisting winch 1 | m/min | 0-137 | |
| Hoisting winch 2 | 0-137 | |||
| Main boom derricking winch | 0-50 | |||
| Luffing jib derricking winch | 0-123 | |||
| Superlift derricking winch | 0-143 | |||
| Hoisting winch 3 | 0-109 | |||
| Slewing speed | rpm | 0-1.0 | ||
| Traveling speed | km/h | 0-1.0 | ||
| Gradeability | % | 30 | ||
| Ground pressure | Mpa | 0.139 | ||
| Transport dimensions of basic machine | mm | 12180×3345×3205 | ||
| Max.transport weight of single piece | 48.6 | |||
| Engine | Rated power / rotational speed | kW/r/min | 360/1800 | |
| Output torque /rotational speed | Nm/r/min | 2200/1300 | ||
| Exhaust emission | EU Stufe 3A | |||
| Distance between track center × crawler contact length × crawler width | mm | |||
